Fumizone - Ozone Based Indoor Air Purifier

FUMIZONE is a portable, ozone based, indoor air purifier for use in offices, clinics, hospitals, homes, shops, restaurants and other indoor spaces where you need to ensure a pure, germ and bacteria-free breathing environment. Fumizone is proudly manufactured in India by OTTPL.

Fumizone - Ozone based, indoor Air Purifier manufactured by OTTPL

Order Now Button OTTPL

Fumizone works on the principle of Ozone Sterilization, and is 100% Safe and effective, does not use any chemicals, does not emit any waste products, and is completely portable.

“WHO has confirmed that COVID-19 is Airborne and remains 8 hours in the Air”
Need of Disinfection

With increased public concern over the adverse effects of various bacteria’s and viruses leading to the transmission of respiratory diseases in indoor environment, to decontaminate these high risk areas, fumigation plays a valuable role in disinfecting all these airborne bacteria’s/viruses/molds and surface attached bacteria’s/viruses/molds. All the possible dangerous hazards because of pathogens, bacteria’s and viruses can be curtailed by fumigating the area. It becomes very imperative that fumigation shall become an integral part of our daily activity in order to safeguard our self from dangerous “COVID-19”

Ozone as a Disinfectant

Ozone owes its excellent bactericidal, virucidal, and germicidal activities to its powerful oxidizing properties. Ozone created by our ozone generators can reach every corner of the environment; Ozone with high oxidizing potential directly attacks the outer shell of bacteria & viruses thereby oxidizing the proteinous material containing RNA and completely kills it.



Salient Features of Fumizone Air Purifier
  • No chemical consumption
  • No waste production
  • Safe & controlled disinfection
  • Handy mobile unit

FUMIZONE - Portable Indoor Air Purifiers - Ozone Based

Order Now Button OTTPL

FUMIZONE is available in various models, depending upon the area of the indoor space to be purified. Some of our most popular models are:

  • FUMIZONE 5X
  • FUMIZONE 10X
  • FUMIZONE 15X
  • FUMIZONE 20X
Technical Specifications
DESCRIPTION
FUMIZONE 5X
FUMIZONE 10X
FUMIZONE 15X
FUMIZONE 20X
Principle
Ozone Sterilization
Ozone Sterilization
Ozone Sterilization
Ozone Sterilization
Material
Mild Steel
internally painted
with ozone
resistant paint
Mild Steel
internally painted
with ozone
resistant paint
Mild Steel
internally painted
with ozone
resistant paint
Mild Steel
internally painted
with ozone
resistant paint
Ozone Output
57×10-
71×10mg/m
11×10-
14×10mg/m
23×10-
28×10mg/m
57×10 -
66×10 mg/m
Unit
Dimensions
3175*280*175 mm
3270*280*175 mm
3270*460*220mm
3270*460*440mm
Weight
4.5 Kg
8 Kg
11 Kg
20 Kg
Cooling
Air-Cooled
Air-Cooled
Air-Cooled
Air-Cooled
Air Flow Volume
85 CFM
190 CFM
344 CFM
690 CFM
Fan Size
4 inch
6 inch
8 inch
8 inch x 2 nos.
Power
52 W
60 W
70 W
140 W
Voltage
220V, 50hz
220V, 50hz
220V, 50hz
220V, 50hz
Noise
<40db
<40db
<40db
<40db
Fuse Holder
1Amp/230AC
2 Amp/230AC
5 Amp/230AC
5 Amp/230AC
Wire Length
2 meter
2 meter
2 meter
2 meter
Timer
Programmable
timer
Programmable
timer
Programmable
timer
Programmable
timer
Operational Chart
AREA
--------
MODEL
100 SQ.
FT.
200 SQ.
FT.
500 SQ.
FT.
1000 SQ.
FT.
2000 SQ.
FT.
FUMIZONE 5X
18 min
36 min
90 min
180 min
360 min
FUMIZONE 10X
8 min
18 min
45 min
80 min
180 min
FUMIZONE 20X
5 min
10 min
25 min
50 min
100 min
FUMIZONE 40X
3 min
6 min
15 min
25 min
60 min
FUMIZONE can be used in the following Applications
  • Odor Removal
  • Schools
  • Hotels
  • Apartments
  • Cars
  • Boats
  • Smoke Damage
  • Houses
  • Hospitals
  • Shops
  • Government & Private Offices
  • Quarantine Centres
